Article: ABT 3350 DS
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | ABT 3350 DS |
| Product ID: | 7TAA261390R0085 |
| EAN: | 0783786785674 |
| Catalog Description: | TRANSF. SPADE CON. 3POS. 350 W/DS |
| Long Description: | Aluminum Transformer Connector, #6 - 500 kcmil, Aluminum and Copper, Bolt size 1/2 inch, Three Conductor |
| |
| EAN: | 0783786785674 |
| |
| Product Net Weight: | 1 lb |
| 453.515 g | |
| |
| Package Level 1 Width: | 7.75 in |
| 197 mm | |
| Package Level 1 Height: | 7 in |
| 178 mm | |
| Package Level 1 Depth / Length: | 13.18 in |
| 335 mm | |
| Package Level 2 Units: | 25 piece |
| Package Level 2 Width: | 8.25 in |
| 210 mm | |
| Package Level 2 Height: | 7.87 in |
| 200 mm | |
| Package Level 2 Depth / Length: | 13.37 in |
| 340 mm | |
| |
| Application: | Pad Mount Transformer Connector |
| Brand / Label: | Homac |
| Connection Type: | Mechanical |
| Insulation Material: | None |
| Material: | Aluminum |
| Number of Batteries: | 0 |
| Number of Conductors: | 3 |
| Product Name: | ELECTRICAL CONNECTOR,<1000V |
| Product Type: | Transformer Spade Connector |
| Special Functions: | Double Set-Screw Series. High Strength Aluminum Alloy maximizes electrical and Mechanical Performance. Ball-Bottom screws ensure Maximum Conductor Contact pressure and break up interstrand oxides. Dual rated to accept Copper or Aluminum conductors. |
| Standards: | ANSI C119.4 |
| UPC: | 783786785674 |
| |
| Data Sheet, Technical Information: | ABT 3350 DS |
| Instructions and Manuals: | ABT 3350 DS |
| |
| UNSPSC: | 39121443 |
| WEEE Category: | Product Not in WEEE Scope |
| IDEA Granular Category Code (IGCC): | 4663 >> Electrical underground bus connector |
