ABW 4350 SLC SB 17BLK X
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | ABW4350 SLC SB 17BLK |
| Product ID: | 7TAA261300R0135 |
| EAN: | 0783786689439 |
| Catalog Description: | ABW 4350 SLC SB 17BLK X |
| Long Description: | Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 12-350, length 5-1/2 in, boot no. SB 17, stud size 5/8, outlets 4, with Street Light Outlet Option, Oxide Inhibitor, with Insulating Boots for Transformer Spade Connector, Black, - 5-15/16 inch long, 2-3/4 inch wide, 3-3/4 inch tall. |
| |
| EAN: | 0783786689439 |
| |
| Product Net Weight: | 1 lb |
| 453.515 g | |
| |
| Package Level 2 Units: | 20 piece |
| Package Level 2 Width: | 1 in |
| 25 mm | |
| Package Level 2 Height: | 1 in |
| 25 mm | |
| Package Level 2 Depth / Length: | 1 in |
| 25 mm | |
| Package Level 3 Depth / Length: | 1 in |
| 25 mm | |
| |
| Application: | Stud Mount Transformer Connector |
| Brand / Label: | Homac |
| Connection Type: | Mechanical |
| Insulation Material: | Insulating Boot |
| Material: | Aluminum |
| Number of Batteries: | 0 |
| Number of Conductors: | 4 |
| Product Name: | ELECTRICAL CONNECTOR <1000V |
| Product Type: | Quick-Disconnect Transformer Connector |
| Special Functions: | In-Line Bar Series. Dual Rated for Aluminum and Copper Conductors. High Strength Aluminum Alloy maintains constant bolting pressure on Conductors. Quick Disconnectability for easy removal from transformer secondary studs. Ball-bottom screws ensure maximum conductor contact pressure and break up interstrand oxides. |
| Standards: | ANSI C119.4 |
| UPC: | 783786689439 |
| |
| Data Sheet, Technical Information: | ABW4350 SLC SB 17BLK |
| Instructions and Manuals: | ABW4350 SLC SB 17BLK |
| |
| UNSPSC: | 39121443 |
| WEEE Category: | Product Not in WEEE Scope |
| IDEA Granular Category Code (IGCC): | 4663 >> Electrical underground bus connector |
