Article: ABB520MI9WN
Article: ABB520MI9WN
Industrial Switched Interlocked Socket Outlets, 3P+N+E, 9 hour, Blue, IP67, 20A, 120/208 ... 144/250V, UL/CSA approved and CE compliant
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | ABB520MI9WN |
| Product ID: | 2CMA105096R1000 |
| EAN: | 7392696050968 |
| Catalog Description: | Industrial Switched Interlocked Socket Outlets, 3P+N+E, 9 hour, Blue, IP67, 20A, 120/208 ... 144/250V, UL/CSA approved and CE compliant |
| Long Description: | IEC Mechanical interlock for 20A and 120/208-144/250V AC 4P5W, UL/CSA/NSF approved and CE compliant |
| |
| EAN: | 7392696050968 |
| Country of Origin: | Czech Republic (CZ) |
| Minimum Order Quantity: | 1 piece |
| |
| Product Net Width: | 160 mm |
| Product Net Height: | 205 mm |
| Product Net Weight: | 1.040 kg |
| |
| Package Level 1 Width: | 339 mm |
| Package Level 1 Depth / Length: | 219 mm |
| Package Level 1 Height: | 169 mm |
| Package Level 1 Gross Weight: | 0.7 kg |
| Package Level 1 EAN: | 7392696058773 |
| Package Level 1 Units: | box 1 piece |
| |
| RoHS Status: | Following EU Directive 2011/65/EU |
| |
| CSA Certificate: | 2CHC660172X0201 |
| Declaration of Conformity - CE: | 2CMC700005D0022 |
| Environmental Information: | 2CMC000057M0000 |
| RoHS Information: | 2CMC700005D0022 |
| UL Certificate: | E109667-20021206 |
| REACH Declaration: | 2CMC700005D0022 |
| |
| Additional Information: | 3P+N+E |
| Ambient Temperature: | -25 ... 40 °C |
| Cable Cross-Section: | 1.5 ... 4 mm² |
| Color: | Blue |
| Connection Type: | Screw |
| Degree of Protection: | IP67 |
| Frequency (f): | 50 Hz |
| 60 Hz | |
| Function: | Outlet |
| Housing Material: | Thermoplastic (PBT) |
| Invoice Description: | Ind. P&S#ABB520MI9WN |
| Mounting Holes: | 130x225 |
| Number of Poles: | 5 |
| Order Multiple: | 1 piece |
| Product Main Type: | CMVS |
| Product Name: | Industrial Switched Interlocked Socket Outlet |
| Rated Current (In): | 20 A |
| Rated Voltage (Ur): | 120/208 ... 144/250 V |
| Standards: | UL 1682, 1686 / CSA C22.2 No. 182.1-13 |
| Suitable for Product Class: | IEC Industrial Plugs and Sockets |
| Instructions and Manuals: | 2CMC000028M0001 |
| Installation Manual: | 2CMC000028M0001 |
| RAL Number: | RAL 7001 - Silver Grey |
| |
| eClass: | 27440510 |
| UNSPSC: | 39122221 |
| |
| Wire Size: | 14 ... 12 AWG |
| Tightening Torque: | WireClamp0.8 N·m |
