Article: DX522-ROB
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | DX522-ROB |
| Product ID: | 1SAP245200R7001 |
| ABB Type Designation: | DX522 |
| EAN: | 4016779782715 |
| Catalog Description: | DX522:S500,Digital I/O.Mod.8DI/8DO-Relay |
| Long Description: | DX522:S500,Digital I/O.Mod.8DI/8DO-Relay DI:24VDC,DO-Relay:230VAC/3A,2/3-wire |
| |
| ABB Type Designation: | DX522 |
| ABS Certificate: | 1SAA960002-0104 |
| Ambient Air Temperature: | Operation 0 ... +60 °C |
| Storage -40 ... +70 °C | |
| BV Certificate: | 1SAA960000-0201 |
| CN8: | 85389091 |
| CSA Certificate: | 1SAA960000-1705 |
| Country of Origin: | Germany (DE) |
| Customs Tariff Number: | 85389091 |
| DNV Certificate: | 1SAA960002-0303 |
| Data Sheet, Technical Information: | 2CDC125002B0206 |
| Declaration of Conformity - CE: | 1SAD938501-0165 |
| Degree of Protection: | IP20 |
| EAN: | 4016779782715 |
| Environmental Information: | 1SAA960009-2401 |
| GL Certificate: | 1SAA960004-0406 |
| GOST Certificate: | 1SAA962000-2701 |
| Gross Weight: | 0.25 kg |
| I/O Option: | IO module with Onboard IO - 8DI / 8DO-R |
| Instructions and Manuals: | 2CDC125080M0202 |
| Invoice Description: | DX522:S500,Digital I/O.Mod.8DI/8DO-Relay |
| LR Certificate: | 1SAA960002-0503 |
| Made To Order: | No |
| Maximum Hardware Counter Input Frequency: | 50 kHz |
| Maximum Operating Altitude Permissible: | 2000 m |
| Minimum Order Quantity: | 1 piece |
| Mounting Position: | Horizontal, Vertical possible with derating |
| Mounting on DIN Rail: | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715 |
| Number of Digital Inputs DC 24V: | 8 |
| Number of Digital Output Relays: | 8 |
| Number of Hardware Counters: | 2 |
| Order Multiple: | 1 piece |
| Output Current: | 3 A |
| Output Voltage (Uout): | 24 ... 230 V AC/DC |
| Package Level 1 Units: | 0 carton |
| Part Type: | New |
| Power Supply: | 24 V DC |
| Primary Voltage: | 24 V DC |
| Product Depth: | 72 mm |
| Product Main Type: | DX522 |
| Product Name: | Distributed Automation I/Os |
| Product Net Height: | 76 mm |
| Product Net Length: | 62 mm |
| Product Net Weight: | 0.18 kg |
| Product Net Width: | 67.5 mm |
| Product Type: | PLC-AC500 |
| Programming Software: | AC500 Control Builder PS501-PROG |
| Quote Only: | Yes |
| RINA Certificate: | 1SAA960003-0804 |
| RMRS Certificate: | 1SAA960001-0704 |
| RoHS Information: | 1SAA960006-4406 |
| Secondary Current: | 0.2 A |
| Selling Unit of Measure: | piece |
| Serial Port 2 Type: | I/O-Bus |
| Short Description: | DX522:S500,Digital I/O.Mod.8DI/8DO-Relay |
| Stocked At (Warehouses): | Menden, Germany |
| Supply Voltage: | 24 V DC |
| UL Certificate: | 1SAA960000-1606 |
| UNSPSC: | 32151705 |
| WEEE B2C / B2B: | Business To Business |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| cUL Certificate: | 1SAA960000-1705 |
| cULus Certificate: | 1SAA960000-1705 |
| eClass: | 27-24-22-04 |
