Article: A26-30-10RT 480V60HZ
Article: A26-30-10RT 480V60HZ
UA26-30-01RA 220-230V50HZ Contactor
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | A26-30-10RT 480V60HZ |
| Product ID: | 1SBL241024R8001 |
| EAN: | 3471522366801 |
| Catalog Description: | UA26-30-01RA 220-230V50HZ Contactor |
| Long Description: | UA26-30-01RA 220-230V50HZ Contactor |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85364900 |
| |
| Product Net Width: | 45 mm |
| Product Net Depth / Length: | 87.3 mm |
| Product Net Height: | 90 mm |
| Product Net Weight: | 0.71 kg |
| |
| Number of Main Contacts NO: | 3 |
| Number of Main Contacts NC: | 0 |
| Number of Auxiliary Contacts NO: | 0 |
| Number of Auxiliary Contacts NC: | 1 |
| Rated Operational Power AC-6b (Pe): | (230 / 240 V) 40 °C, 50 / 60 Hz 12 kvar |
| (230 / 240 V) 55 °C, 50 / 60 Hz 11 kvar | |
| (230 / 240 V) 70 °C, 50 / 60 Hz 8.5 kvar | |
| (400 / 415 V) 40 °C, 50 / 60 Hz 20 kvar | |
| (400 / 415 V) 70 °C, 50 / 60 Hz 14.5 kvar | |
| (400 / 415 V) 55 °C, 50 / 60 Hz 18.5 kvar | |
| (440 V) 40 °C, 50 / 60 Hz 22 kvar | |
| (440 V) 55 °C, 50 / 60 Hz 20 kvar | |
| (440 V) 70 °C, 50 / 60 Hz 16 kvar | |
| (500 / 550 V), 40 °C, 50 / 60 Hz 22 kvar | |
| (500 / 550 V) 55 °C, 50 / 60 Hz 22 kvar | |
| (500 / 550 V) 70 °C, 50 / 60 Hz 19.5 kvar | |
| (690 V) 40 °C, 50 / 60 Hz 30 kvar | |
| (690 V) 55 °C, 50 / 60 Hz 30 kvar | |
| (690 V) 70 °C, 50 / 60 Hz 25 kvar | |
| Rated Control Circuit Voltage (Uc): | 50 Hz 220 ... 230 V |
| 60 Hz 230 ... 240 V | |
| Terminal Type: | Screw Terminals |
| |
| RoHS Status: | Following EU Directive 2011/65/EU |
| |
| CB Certificate: | CB_FR_596544 |
| Declaration of Conformity - CE: | 1SBD250810U1000 |
| EAC Certificate: | EAC_RU C-FR ME77 B03599 |
| RoHS Information: | 1SBD250810U1000 |
| |
| Package Level 1 Units: | box 1 piece |
| Package Level 1 Width: | 135 mm |
| Package Level 1 Depth / Length: | 155 mm |
| Package Level 1 Height: | 63 mm |
| Package Level 1 Gross Weight: | 0.71 kg |
| Package Level 1 EAN: | 3471522366801 |
| Package Level 2 Units: | box 63 piece |
| Package Level 2 Gross Weight: | 44.73 kg |
| |
| ETIM 6: | EC001079 - Capacitor contactor |
| ETIM 7: | EC001079 - Capacitor contactor |
| eClass: | V11.0 : 27371006 |
