Article: 9049M5
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | 9049M5 |
| Product ID: | 7TBA010800R0078 |
| EAN: | 0622538059031 |
| Catalog Description: | 3/8 IN NMD90 STEEL CONNECTOR PKG/5 |
| Long Description: | Fitting, One Screw, Trade Size 3/8 Inch, Clamping Range 0.13 Inch - 0.37 Inch, Zinc Alloy, Suggested Application 14/2-10/2, 14/3-12/3 |
| |
| EAN: | 0622538059031 |
| |
| Package Level 1 Units: | 12 piece |
| Package Level 1 Width: | 6.06 in |
| 154 mm | |
| Package Level 1 Height: | 7.38 in |
| 187 mm | |
| Package Level 1 Depth / Length: | 7.25 in |
| 184 mm | |
| Package Level 2 Units: | 2160 piece |
| Package Level 2 Width: | 40 in |
| 1016 mm | |
| Package Level 2 Height: | 41.9 in |
| 1064 mm | |
| Package Level 2 Depth / Length: | 48 in |
| 1219 mm | |
| |
| Application: | For 14/2-10/2; 14/3-12/3 |
| Brand / Label: | Steel City / Iberville |
| Effective Date: | 19990127 |
| Material: | Zinc Alloy |
| Nominal Size: | 3/8 in |
| Number of Batteries: | 0 |
| Product Name: | 3/8 IN NMD90 STEEL CONNECTOR |
| Product Type: | Fitting, One Screw |
| Standards: | CSA 3313 |
| UPC: | 622538059031 |
| |
| Data Sheet, Technical Information: | 9049M5 |
| Instructions and Manuals: | 9049M5 |
| |
| ETIM 6: | EC001180 - Screw connection for protective metallic hose |
| ETIM 7: | EC001180 - Screw connection for protective metallic hose |
| UNSPSC: | 39121719 |
| WEEE Category: | Product Not in WEEE Scope |
| IDEA Granular Category Code (IGCC): | 5067 >> Strain reliefs |
