Article: KS878
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | KS878 |
| Product ID: | 2CPX032653R9999 |
| EAN: | 4011617326533 |
| Catalog Description: | KS878 Residential incomer cabinet |
| Long Description: | House service connection cabinet |
| |
| Product Name: | Residential incomer cabinet |
| Rated Current (In): | 500 A |
| Number of Meter Cabinets: | 0 |
| Number of Panel Widths: | 4 |
| Number of Rows: | 0 |
| Number of TSG Panels: | 0 |
| Lower Connection Space: | with Bus Bar |
| Enclosure Type: | Residential incomer cabinet |
| Enclosure Type of Height: | 4 |
| Mounting Type: | Surface-mounted |
| Door Type: | Double |
| Surface Finishing: | powder-coated |
| Housing Material: | Steel |
| Material: | Steel plate |
| DIN Place Units: | 480 |
| Model Number: | eHZ |
| RAL Number: | RAL 7035 - Light Grey |
| Color: | Light grey |
| |
| Degree of Protection: | IP54 |
| Protection Class: | Grounded |
| SCIP: | 29b0f087-c231-4008-b064-9a506b680daa Germany (DE) |
| Simplified SCIP: | 29b0f087-c231-4008-b064-9a506b680daa Germany (DE) |
| |
| Product Net Width: | 1300 mm |
| Product Net Height: | 1250 mm |
| Product Net Depth / Length: | 350 mm |
| Product Net Weight: | 93.131 kg |
| Built-In Depth (t2): | 350 mm |
| |
| Package Level 1 Units: | pack 1 piece |
| Package Level 1 Width: | 1340.000 mm |
| Package Level 1 Height: | 1290.000 mm |
| Package Level 1 Depth / Length: | 390.000 mm |
| Package Level 1 Gross Weight: | 96.9 kg |
| Package Level 1 EAN: | 4011617326533 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85371098 |
| Country of Origin: | Germany (DE) |
| Selling Unit of Measure: | piece |
| |
| Declaration of Conformity - CE: | No declaration needed |
| Instructions and Manuals: | No document needed |
| Popular Downloads | |
| Data Sheet, Technical Information: | 2CPC000003B0101 |
| Instructions and Manuals: | No document needed |
| |
| ETIM 6: | EC000262 - Meter cabinet equipped |
| ETIM 7: | EC000262 - Meter cabinet equipped |
| ETIM 8: | EC000262 - Meter cabinet equipped |
| EPLAN Catalog Tree: | Mechanics / Housings / General |
| WEEE Category: | 4. Large Equipment (Any External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Business |
| CN8: | 85371098 |
| Object Classification Code: | U |
