Article: SRO/U1.1.2
Article: SRO/U1.1.2
SRO/U1.1.2 Solo Room Temperature Controller Commercial, white, FM
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | SRO/U1.1.2 |
| Product ID: | 2CDG006134R0308 |
| EAN: | 4011395189115 |
| Catalog Description: | SRO/U1.1.2 Solo Room Temperature Controller Commercial, white, FM |
| Long Description: | SRO/U1.1.2 Solo Room Temperature Controller Commercial, white, FM |
| |
| Standards: | DIN EN 50090-2-2: 1996+Corrigendum:1997+A1:2002+A2:2007 |
| Product Name: | User Operation - Solo |
| Power Loss: | 0.3 W |
| Compatible Bus Systems: | KNX (TP) |
| Mounting Type: | Flush Mounted |
| Manual Operation: | No |
| Color: | Studio white |
| Number of Batteries: | 0 |
| |
| Degree of Protection: | IP20 |
| |
| Product Net Width: | 45 mm |
| Product Net Height: | 23 mm |
| Product Net Depth / Length: | 50 mm |
| Product Net Weight: | 0.053 kg |
| |
| Package Level 1 Units: | box 1 piece |
| Package Level 1 Width: | 92 mm |
| Package Level 1 Height: | 78 mm |
| Package Level 1 Depth / Length: | 58 mm |
| Package Level 1 Gross Weight: | 0.096 kg |
| Package Level 1 EAN: | 4011395189115 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85371098 |
| Replacement Product ID (NEW): | 2CKA006134A0308 |
| Country of Origin: | Germany (DE) |
| Selling Unit of Measure: | piece |
| |
| Declaration of Conformity - CE: | 9AKK2017-108547 |
| |
| ETIM 6: | EC001101 - Room temperature controller for bus system |
| ETIM 7: | EC001101 - Room temperature controller for bus system |
| ETIM 8: | EC001101 - Room temperature controller for bus system |
| EPLAN Catalog Tree: | Electrical engineering / Sensor, switch, and pushbutton / Switch , pushbutton |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Consumer |
| CN8: | 8537 10 98 |
| eClass: | V11.0 : 27143133 |
| Object Classification Code: | A |
