General Information | |
| Extended Product Type: | SUP403M-K2 |
| Product ID: | 2CCG000119R0001 |
| EAN: | 7612271506612 |
| Catalog Description: | SUP403M-K2 Miniature Circuit Breaker |
| Long Description: | Pluggable Miniature circuit-breaker for the SMISSLINE TP System acc. UL489 in 277/480 VAC systems, Tripping characteristic K, Rated current In 2A |
| |
| Product Name: | Miniature Circuit Breaker |
| Tripping Characteristic: | K |
| Rated Operational Voltage: | acc. to IEC 60947-2 480 V |
| Rated Insulation Voltage (Ui): | acc. to IEC/EN 60664-1 440 V |
| Rated Impulse Withstand Voltage (Uimp): | 4 kV |
| Input Voltage Type: | AC |
| Rated Current (In): | 2 A |
| Rated Frequency (f): | 50 ... 60 Hz |
| Power Loss: | 3.9 W |
| Energy Limiting Class: | 3 |
| Number of Poles: | 3 |
| Number of Protected Poles: | 3 |
| Overvoltage Category: | III |
| Accessories Available: | Yes |
| Number of Batteries: | 0 |
| Connecting Capacity: | Flexible 0.75 ... 25 mm² |
| Rigid 0.75 ... 35 mm² | |
| |
| Ambient Air Temperature: | Operation 40 ... 40 °C |
| Degree of Protection: | IP20 |
| Pollution Degree: | 2 |
| RoHS Status: | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
| |
| Width in Number of Modular Spacings: | 54 |
| Product Net Width: | 54 mm |
| Product Net Height: | 102 mm |
| Product Net Depth / Length: | 74.5 mm |
| Product Net Weight: | 360 g |
| Built-In Depth (t2): | 102 mm |
| |
| Package Level 1 Units: | carton 1 piece |
| Package Level 1 Width: | 98 mm |
| Package Level 1 Height: | 105 mm |
| Package Level 1 Depth / Length: | 182 mm |
| Package Level 1 Gross Weight: | 418 g |
| Package Level 1 EAN: | 7612271506612 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85362020 |
| Country of Origin: | Switzerland (CH) |
| Selling Unit of Measure: | piece |
| |
| Declaration of Conformity - CE: | No declaration needed |
| Instructions and Manuals: | No document needed |
| RoHS Information: | 2CCC005062D0201_RoHS SU400M_SUP400M |
| Popular Downloads | |
| Data Sheet, Technical Information: | 9AKK107492A6192 |
| Instructions and Manuals: | No document needed |
| |
| ETIM 6: | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 7: | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 8: | EC000042 - Miniature circuit breaker (MCB) |
| EPLAN Catalog Tree: | Electrical engineering / Protection devices / General |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Business |
| CN8: | 85362020 |
| Object Classification Code: | F |
