NotAvailable Control and Automation Board
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | NotAvailable |
| Product ID: | SRN12840K |
| EAN: | 8015646807045 |
| Catalog Description: | NotAvailable Control and Automation Board |
| Long Description: | ENCLOSURE BL.DOOR+PLATE1200X800X400 7035;ENCLOSURE BL.DOOR+PLATE1200X800X400 7035 |
| |
| Product Name: | Control and Automation Board |
| Suitable for Product Class: | SR2 |
| Number of Flange Openings: | 2 |
| Cover Plate Type: | Door |
| Enclosure Type NEMA: | Type4X |
| Mounting Type: | Surface mounted (plaster) |
| Door Type: | Single |
| Surface Finishing: | Powder coating |
| Construction Material: | Galvanized steel |
| Door Surface Finishing: | Opaque |
| Housing Material: | Steel |
| RAL Number: | RAL 7035 - Light Grey |
| Color: | Grey |
| Thickness: | Cabinet plate 1.2 mm |
| Door plate 1.2 mm | |
| |
| Degree of Protection: | IP65 |
| Protection Class: | Grounded |
| |
| Product Net Width: | 800 mm |
| Product Net Height: | 1200 mm |
| Product Net Depth / Length: | 400 mm |
| Product Net Weight: | 61.210 kg |
| Built-In Depth (t2): | 400 mm |
| |
| Package Level 1 Units: | box 1 piece |
| Package Level 1 Width: | 820.000 mm |
| Package Level 1 Height: | 325.000 mm |
| Package Level 1 Depth / Length: | 1230.000 mm |
| Package Level 1 Gross Weight: | 61.210 kg |
| Package Level 1 EAN: | 8015646807045 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85381000 |
| Country of Origin: | Italy (IT) |
| Selling Unit of Measure: | piece |
| |
| Declaration of Conformity - CE: | No declaration needed |
| Instructions and Manuals: | No document needed |
| Popular Downloads | |
| Data Sheet, Technical Information: | No document needed |
| Instructions and Manuals: | No document needed |
| |
| ETIM 6: | EC000058 - Empty cabinet |
| ETIM 7: | EC000058 - Empty cabinet |
| ETIM 8: | EC000058 - Empty cabinet |
| WEEE Category: | Product Not in WEEE Scope |
