Article: RLV232
Article: RLV232
Industrial Socket Outlet Panel Mounting, 2P, 32 A, 20 … 25 AC V
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | RLV232 |
| Product ID: | 2CMA100979R1000 |
| EAN: | 7392696009799 |
| Catalog Description: | Industrial Socket Outlet Panel Mounting, 2P, 32 A, 20 … 25 AC V |
| Long Description: | Industrial Socket Outlet Panel Mounting Extra low voltage 32 A, RLV 232, splashproof |
| |
| E-Number (Sweden): | E2417752 |
| EAN: | 7392696009799 |
| Country of Origin: | Austria (AT) |
| Minimum Order Quantity: | 10 piece |
| |
| Product Net Width: | 55 mm |
| Product Net Height: | 79 mm |
| Product Net Weight: | 0.099 kg |
| |
| Package Level 1 Width: | 62 mm |
| Package Level 1 Depth / Length: | 62 mm |
| Package Level 1 Height: | 81 mm |
| Package Level 1 Gross Weight: | 0.99 kg |
| Package Level 1 EAN: | 7392696010030 |
| Package Level 1 Units: | box 10 piece |
| |
| RoHS Status: | Following EU Directive 2011/65/EU |
| |
| Declaration of Conformity - CE: | 2CMC700005D0001 |
| Environmental Information: | 2CMC000072M0000 |
| RoHS Information: | 2CMC700005D0001 |
| REACH Declaration: | 2CMC700005D0001 |
| |
| Additional Information: | 2P |
| Ambient Temperature: | -25 ... 40 °C |
| Cable Cross-Section: | 1 … 10 mm² |
| Cable Diameter: | 8 ... 24 mm |
| Color: | Purple |
| Connection Type: | Screw |
| Degree of Protection: | IP44 |
| Function: | Extra low voltage panel mounted socket |
| Housing Material: | Plastic |
| Invoice Description: | Ind. P_S#RLV232 |
| Mounting Holes: | 44x44 |
| Number of Poles: | 2 |
| Order Multiple: | 10 piece |
| Product Main Type: | RLV |
| Product Name: | Extra low voltage panel mounted socket |
| Protection Type: | Splashproof |
| Rated Current (In): | 32 A |
| Rated Frequency (f): | 50...60 Hz |
| Rated Voltage (Ur): | 20 … 25 V |
| Standards: | IEC 60309-1, -2 |
| Suitable for Product Class: | IEC Industrial Plugs and Sockets |
| Instructions and Manuals: | 2CMC700014C0016 |
| RAL Number: | RAL 7001 - Silver Grey |
| |
| eClass: | 27440504 |
| UNSPSC: | 39120000 |
