Article: AMTD-1-R P
We find the right product
for you
Official reseller
Expert engineering support
Configuration
):
General Information | |
| Extended Product Type: | AMTD-1-R P |
| Product ID: | 2CSG213645R4011 |
| EAN: | 8012542136453 |
| Catalog Description: | AMTD-1-R P Digital Ammeter |
| Long Description: | AMTD-1-R P is a front-panel digital ammeter for ac networks, with programmable relay |
| |
| Product Name: | Digital Ammeter |
| Current Type: | AC |
| Frequency (f): | 35 ... 400 Hz |
| Power Consumption (@P | |
| cons | 4 W |
| Power Loss: | 4 W |
| Accuracy: | ±0,5% F.S. ±1digit at 25 °C |
| Measurement Scale: | End 600 A |
| Measuring Range: | 5...600 A |
| Meter Type: | Digital |
| Mounting Type: | Front-panel |
| Accessories Available: | Yes |
| Model Number: | Front mounting |
| |
| Ambient Air Temperature: | Operation -40 ... 55 °C |
| Degree of Protection: | IP20 |
| RoHS Status: | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
| Environmental Information: | See RoHS Information |
| |
| Product Net Width: | 72 mm |
| Product Net Height: | 26.5 mm |
| Product Net Depth / Length: | 61.5 mm |
| Product Net Weight: | 0.350 kg |
| |
| Package Level 1 Units: | box 1 piece |
| Package Level 1 Width: | 0.045 m |
| Package Level 1 Height: | 0.07 m |
| Package Level 1 Depth / Length: | 0.115 m |
| Package Level 1 Gross Weight: | 0.65 kg |
| Package Level 1 EAN: | 8012542136453 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 90303100 |
| Country of Origin: | Romania (RO) |
| Selling Unit of Measure: | piece |
| |
| Declaration of Conformity - CE: | 9AKK106713A5697 |
| Environmental Information: | See RoHS Information |
| Instructions and Manuals: | No document needed |
| RoHS Information: | 2CSC445007K0201 |
| Popular Downloads | |
| Data Sheet, Technical Information: | 9AKK107046A0430 |
| Instructions and Manuals: | No document needed |
| |
| ETIM 6: | EC002292 - Ampere meter for installation |
| ETIM 7: | EC002292 - Ampere meter for installation |
| ETIM 8: | EC002292 - Ampere meter for installation |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Consumer |
| CN8: | 90303100 |
| Object Classification Code: | P |
