Article: AMT1-A1-30/96
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | AMT1-A1-30/96 |
| Product ID: | 2CSG313080R4001 |
| EAN: | 8012542548706 |
| Catalog Description: | AMT1-A1-30/96 Analogue Ammeter |
| Long Description: | AMT1-A1-30/96 is a 96x96mm fonrt-panel analogue ammeter used in ac networks. Direct insertion. |
| |
| Product Name: | Analogue Ammeter |
| Current Type: | AC |
| Current Range: | 30 A |
| Power Loss: | 1.2 W |
| Accuracy: | ±1,5% |
| Measurement Scale: | End 30 A |
| Measuring Range: | 0...30 A |
| Needle Deflection: | Maximum 90 ° |
| Meter Type: | Analogue |
| Mounting Type: | Front-panel |
| Model Number: | Front mounting |
| |
| Ambient Air Temperature: | Operation -40 ... 55 °C |
| Degree of Protection: | IP52 |
| RoHS Status: | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
| Environmental Information: | See RoHS Information |
| |
| Product Net Width: | 96 mm |
| Product Net Height: | 0.096 m |
| Product Net Depth / Length: | 53 mm |
| Product Net Weight: | 0.400 kg |
| Dimensions: | 96 mm x 96 mm |
| |
| Package Level 1 Units: | box 1 piece |
| Package Level 1 Width: | 0.12 m |
| Package Level 1 Height: | 0.1 m |
| Package Level 1 Depth / Length: | 0.1 m |
| Package Level 1 Gross Weight: | 0.4 kg |
| Package Level 1 EAN: | 8012542548706 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 90303100 |
| Country of Origin: | Italy (IT) |
| Selling Unit of Measure: | piece |
| |
| Declaration of Conformity - CE: | 9AKK106713A5695 |
| Environmental Information: | See RoHS Information |
| Instructions and Manuals: | No document needed |
| RoHS Information: | 2CSC445003K0201 |
| Popular Downloads | |
| Data Sheet, Technical Information: | 9AKK107046A0430 |
| Instructions and Manuals: | No document needed |
| |
| ETIM 6: | EC002292 - Ampere meter for installation |
| ETIM 7: | EC002292 - Ampere meter for installation |
| ETIM 8: | EC002292 - Ampere meter for installation |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Consumer |
| CN8: | 90303100 |
| Object Classification Code: | P |
