General Information | |
| Extended Product Type: | 463P4 |
| Product ID: | 2CMA101862R1000 |
| EAN: | 7392696018623 |
| Catalog Description: | 463P4 Industrial plug |
| Long Description: | Plug, earthing sleeve position 4h, rated current 63A, IP44 splashproof, 3-poles+neutral+earth, frequency 50-60 Hz, color code Yellow |
| |
| EAN: | 7392696018623 |
| Country of Origin: | Czech Republic (CZ) |
| Minimum Order Quantity: | 1 piece |
| |
| Product Net Width: | 103 mm |
| Product Net Height: | 103 mm |
| Product Net Weight: | 0.720 kg |
| |
| Package Level 1 Width: | 114 mm |
| Package Level 1 Depth / Length: | 114 mm |
| Package Level 1 Height: | 230 mm |
| Package Level 1 Gross Weight: | 0.720 kg |
| Package Level 1 EAN: | 7392696018623 |
| Package Level 1 Units: | box 1 piece |
| |
| Declaration of Conformity - CE: | 2CMC700005D0001 |
| |
| Additional Information: | 3P+N+E |
| Ambient Temperature: | -25 ... 40 °C |
| Cable Cross-Section: | 4 ... 16 mm² |
| Color: | Yellow |
| Connection Type: | Screw |
| Degree of Protection: | IP44 |
| Function: | Plug |
| Invoice Description: | Ind. P&S#463P4 |
| Number of Poles: | 5 |
| Product Main Type: | TP |
| Product Name: | Industrial plug |
| Rated Current (In): | 63 A |
| Rated Voltage (Ur): | 57/100 ... 75/130 V |
| Suitable for Product Class: | IEC Industrial Plugs and Sockets |
| Instructions and Manuals: | 2CMC000040M0001 |
| Installation Manual: | 2CMC000040M0001 |
| RAL Number: | RAL 7001 - Silver Grey |
| |
| Wire Size: | 8 ... 4 AWG |
| Tightening Torque: | WireClamp3.5 N·m |
