Article: MCB-20G
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | MCB-20G |
| Product ID: | 1SFA611610R1102 |
| EAN: | 7320500544389 |
| Catalog Description: | MCB-20G Contact Block |
| Long Description: | Modular contact block |
| |
| Minimum Order Quantity: | 10 piece |
| Customs Tariff Number: | 8536901000 |
| Popular Downloads | |
| Data Sheet, Technical Information: | 1SFC151007C02__ |
| Instructions and Manuals: | 1SFC151011M0201 |
| |
| Product Net Width: | 0.02 m |
| Product Net Height: | 0.044 m |
| Product Net Depth / Length: | 0.028 m |
| Product Net Weight: | 0.026 kg |
| |
| Ambient Air Temperature: | Operation -25 ... +70 °C |
| Storage -40 ... +85 °C | |
| Illumination: | Non-illuminated |
| Function: | Without holder |
| Mounting Type: | Front mounting |
| Number of Auxiliary Contacts NO: | 2 |
| Degree of Protection: | Terminals IP20 |
| Rated Frequency (f): | Supply Circuit 50 / 60 Hz |
| Rated Operational Voltage: | Maximum 690 V AC/DC |
| Rated Operational Current DC-13 (Ie): | (24 V) 5 A |
| (125 V) 1.1 A | |
| Rated Operational Current AC-15 (Ie): | (230 V AC) 6 A |
| Power Loss: | Maximum 5 W |
| Connecting Capacity Main Circuit: | Flexible with Ferrule 1/2x 0.75 ... 2.5 mm² |
| Flexible with Insulated Ferrule 1x 0.75 ... 2.5 mm² | |
| Flexible with Insulated Ferrule 2x 0.75 ... 2.5 mm² | |
| Flexible 1 x 0.75 ... 2.5 mm² | |
| Flexible 2 x 0.75 ... 2.5 mm² | |
| Solid 1 x0.75...2.5 mm² | |
| Solid 2 x0.75...2.5 mm² | |
| Terminal Type: | Screw Terminals |
| Tightening Torque: | 0.9 N·m |
| Wire Stripping Length: | 8 mm |
| |
| RoHS Status: | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date: | 0635 4 |
| RoHS Information: | 2CMT2015-005452 |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Business |
| |
| CB Certificate: | SEMKO_SE30016M2 |
| CQC Certificate: | CQC2005010304154103 |
| cULus Certificate: | UL-E76003-20140513 |
| Declaration of Conformity - CCC: | 2020980305001528 |
| Declaration of Conformity - CE: | 2CMT2015-005452 |
| DNV GL Certificate: | E-14107 |
| EAC Certificate: | RU C-CN.ME77.B.01927 |
| Environmental Information: | 1SAC200074H0001 |
| Instructions and Manuals: | 1SFC151011M0201 |
| RoHS Information: | 2CMT2015-005452 |
| |
| Package Level 1 Units: | bag 10 piece |
| Package Level 1 Width: | 0.11 m |
| Package Level 1 Depth / Length: | 0.15 m |
| Package Level 1 Height: | 0.02 m |
| Package Level 1 Gross Weight: | 0.26 kg |
| Package Level 1 EAN: | 7320500338469 |
| |
| Object Classification Code: | S |
| ETIM 4: | EC002024 - Accessories for control circuit devices |
| ETIM 5: | EC000041 - Auxiliary contact block |
| ETIM 6: | EC000041 - Auxiliary contact block |
| ETIM 7: | EC000041 - Auxiliary contact block |
| eClass: | V11.0 : 27371302 |
| UNSPSC: | 39121500 |
