Article: CA5D-11
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | CA5D-11 |
| Product ID: | 1SBN010344R3413 |
| EAN: | 3471522199683 |
| Catalog Description: | CA5D-11 Auxiliary Contact Block |
| Long Description: | CA5D-11 Auxiliary Contact Block |
| |
| Product Name: | Auxiliary Contact Block |
| Rated Operational Current AC-15 (Ie): | (500 V) 2 A |
| (690 V) 2 A | |
| (24 / 127 V) 6 A | |
| (220 / 240 V) 4 A | |
| (380 / 400 V) 3 A | |
| Number of Auxiliary Contacts NC: | 1 |
| Number of Auxiliary Contacts NO: | 1 |
| Mounting Type: | Front mounting |
| Terminal Type: | Screw Terminals |
| |
| RoHS Status: | Following EU Directive 2011/65/EU |
| Environmental Information: | 1SBD250132E1001 |
| |
| Product Net Width: | 43 mm |
| Product Net Height: | 47 mm |
| Product Net Depth / Length: | 39 mm |
| Product Net Weight: | 0.06 kg |
| |
| Package Level 1 Units: | 2 piece |
| Package Level 1 Width: | 65 mm |
| Package Level 1 Height: | 43 mm |
| Package Level 1 Depth / Length: | 129.5 mm |
| Package Level 1 Gross Weight: | 0.12 kg |
| Package Level 1 EAN: | 3471522199683 |
| Package Level 2 Units: | 32 piece |
| Package Level 2 Gross Weight: | 1.92 kg |
| Package Level 3 Units: | 2880 piece |
| |
| Minimum Order Quantity: | 2 piece |
| Customs Tariff Number: | 85389099 |
| Country of Origin: | Czech Republic (CZ) |
| Selling Unit of Measure: | piece |
| |
| CQC Certificate: | CQC2015010304800518 |
| CQC2004010305133985 | |
| Declaration of Conformity - CCC: | 2020980304001627 |
| 2020980305001185 | |
| Declaration of Conformity - CE: | 1SBD250809U1000 |
| EAC Certificate: | EAC_RU C-FR ME77 B03391 |
| Environmental Information: | 1SBD250132E1001 |
| GOST Certificate: | GOST_POCCFRME77B07175 |
| Instructions and Manuals: | FPTC407783P0001 |
| RINA Certificate: | RINA_ELE172319XG001 |
| RoHS Information: | 1SBD250809U1000 |
| Popular Downloads | |
| Data Sheet, Technical Information: | 1SBC100122C0202_Ch04 |
| Instructions and Manuals: | FPTC407783P0001 |
| |
| ETIM 6: | EC000041 - Auxiliary contact block |
| ETIM 7: | EC000041 - Auxiliary contact block |
| ETIM 8: | EC000041 - Auxiliary contact block |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Business |
| CN8: | 8538 90 99 |
| UNSPSC: | 39121500 |
| Object Classification Code: | K |
