C513-W Temperature monitoring relay Temperature range -50...+500°C
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | C513-W |
| Product ID: | 1SAR700110R0010 |
| EAN: | 4013614338069 |
| Catalog Description: | C513-W Temperature monitoring relay Temperature range -50...+500°C |
| Long Description: | Temperature monitoring relay C513-W, width 45mm, digital adjustable, 2 therschholds, exceeding/parces below, window monitoring, A1-A2=24-240V AC / DC, 1 c/o, 1 c/o, 1 n/o |
| |
| EAN: | 4013614338069 |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85364900 |
| Replacement Product ID (NEW): | 1SVR750740R0110 |
| Popular Downloads | |
| Data Sheet, Technical Information: | 2CDC110004C0209 |
| Instructions and Manuals: | 2CDC112095M9701 |
| |
| Product Net Width: | 45 mm |
| Product Net Depth / Length: | 92 mm |
| Product Net Height: | 105.9 mm |
| Product Net Weight: | 0.307 kg |
| |
| Function: | Overtemperature monitoring |
| Undertemperature monitoring | |
| Over- and undertemperature monitoring | |
| Measuring Range: | -50 ... +500 °C |
| Sensor Type: | PT100; PT1000; KTY83; KTY84; NTC |
| Rated Control Supply Voltage (Us): | 24 ... 240 V AC/DC |
| Output: | 2 c/o (SPDT) + 1 n/o contacts |
| Terminal Type: | Screw Terminals |
| Standards: | CAN/CSA C22.2 No.14 |
| IEC/EN 63000 | |
| IEC/EN 60947-5-1 | |
| UL 508 | |
| |
| RoHS Status: | Following EU Directive 2011/65/EU |
| |
| cUL Certificate: | cUL508_E140448 |
| Data Sheet, Technical Information: | 2CDC110004C0209 |
| Declaration of Conformity - CE: | 1SVD981035-0001 |
| Environmental Information: | 1SAA981003-2403 |
| Instructions and Manuals: | 2CDC112095M9701 |
| RoHS Information: | 1SVD981035-0001 |
| UL Certificate: | UL508_E140448 |
| |
| Package Level 1 Units: | 1 piece |
| Package Level 1 Width: | 112 mm |
| Package Level 1 Height: | 105 mm |
| Package Level 1 Depth / Length: | 53 mm |
| Package Level 1 Gross Weight: | 0.333 kg |
| Package Level 1 EAN: | 4013614338069 |
| |
| Object Classification Code: | B |
| ETIM 4: | EC001446 - Temperature monitoring relay |
| ETIM 5: | EC001446 - Temperature monitoring relay |
| ETIM 6: | EC001446 - Temperature monitoring relay |
| ETIM 7: | EC001446 - Temperature monitoring relay |
| eClass: | V11.0 : 27371810 |
