Article: LS43P53B11
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | LS43P53B11 |
| Product ID: | 1SBV010753R1211 |
| EAN: | 3471522000002 |
| Catalog Description: | LS43P53B11 Limit Switch |
| Long Description: | LS43P53B11 is a 40 mm wide, standard reinforced Limit Switch made of fiber-glass reinforced UL-V0 material, with 4 mounting holes at the top and bottom, 1 ISO M20x1.5 cable entry on the bottom, adjustable steel roller lever (Ø22 mm) mouted on roller bearing actuator and 1 N.O + 1 N.C snap action (Zb type) contacts |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85364900 |
| Popular Downloads | |
| Data Sheet, Technical Information: | 1SBC141157C0202 |
| Instructions and Manuals: | 1SBC141157C0202 |
| |
| Product Net Width: | 41 mm |
| Product Net Height: | 135 mm |
| Product Net Depth / Length: | 62 mm |
| Product Net Weight: | 0.174 kg |
| |
| CQC Certificate: | CQC2004010305127663 |
| cUL Certificate: | 9AKK107991A7379 |
| Declaration of Conformity - CCC: | 2020980305001785 |
| Declaration of Conformity - CE: | 1SBD250883U1000 |
| Declaration of Conformity - UKCA: | 1SBD250886U1000 |
| Instructions and Manuals: | 1SBC141157C0202 |
| |
| Package Level 1 Units: | box 1 piece |
| Package Level 1 Gross Weight: | 0.195 kg |
| |
| ETIM 6: | EC000030 - End switch |
| ETIM 7: | EC000030 - End switch |
| UNSPSC: | 39121500 |
