General Information
Global Commercial Alias:	EL3403
Product ID:	7BEL3403
ABB Type Designation:	.25HP,1745RPM,1PH,60HZ,48,3414LC,TE
Catalog Description:	.25HP,1745RPM,1PH,60HZ,48,3414LC,TEFC,F1
Additional Information
ABB Type Designation:	.25HP,1745RPM,1PH,60HZ,48,3414LC,TE
Altitude:	1000 m
Ambient Temperature:	40 °C
Bearing:	6203
Bearing NDE:	6203
Brake Present:	No
Brand / Label:	Baldor-Reliance
Catalog Number:	EL3403
Certification Agency:	CSA
CSA EEV
UR
Country of Origin:	United States (US)
Customs Tariff Number:	85013100
Dimension Diagram:	34LYG374
Direction of Rotation:	Both sides
Drive End Flange Type:	Standard
Duty Time:	60 Min
ETIM 7:	EC001851 - Electric motor
Efficiency Level:	2015 Small Motor Standard
Not Regulated / Exempt

Electrical Data:

Current	Freq	Power	Speed	Voltage
2.5 A	60 Hz	.25 Hp	1745 r/min	115 V
1.25 A	60 Hz	.25 Hp	1745 r/min	230 V

Enclosure Type: TEFC
Frame Material: Steel
Frequency (f): 60.00 Hz
Global Commercial Alias: EL3403
Gross Volume: 2205.33 in³
Gross Weight: 10.896 kg
Horsepower Rating UL/CSA: 0.250 Hp
IC Class: TEFC
IDEA Granular Category Code (IGCC): 1329 >> Single phase motor AC
IE Class Data (50 Hz): IE Class NA
IE Class Data (60 Hz): IE Class NA
IM Class: F1
Insulation Class: F
Invoice Description: .25HP,1745RPM,1PH,60HZ,48,3414LC,TEFC,F1
Lubrication: Regreasable
Made To Order: No
Minimum Order Quantity: 1 piece
Motor Base Type: Rigid
Motor Frame Size: 48
Mounting Position: F1
Number of Phases: 1
Number of Poles: 4
Number of Speeds: Single Speed
Order Multiple: 1 piece
Output Power: 0.250 Hp
Power Factor: 89 %
Product Name: GP 1PH Enclosed
Product Net Height: 28.893 cm
Product Net Length: 41.91 cm
Product Net Weight: 10.896 kg
Product Net Width: 29.845 cm
Product Type: Undefined
Quote Only: No
Rated Current (I_n): 2.5 A

1.25 A
Rated Efficiency: 74.0 %
Rated Speed: 1,745 r/min
RoHS Information: RoHS Compliant
Selling Unit of Measure: piece
Service Factor: 1.35
Service Factor Percentage: 1.35 %
Shaft Diameter: 0.500 in
Standards: NEMA
Starting of Motor: Direct On Line
Stocked At (Warehouses): China

Alabama, United States

Alaska, United States
Temperature Class Default: --
Two Speed Motor: No
Type of Duty: Continuous
UNSPSC: 26101116
Voltage Code: K
Voltage Rating: 115 V

230 V
