Article: 2CSK1202CH
Article: 2CSK1202CH
Summer/winter electronic thermostat, relay output, 1 NO contact 8A (AC1)/2A (AC15) - Power supply 230V~ 50/60Hz
We find the right product
for you
Official reseller
Expert engineering support
Configuration
):
General Information | |
| Product ID: | 2CSK1202CH |
| EAN: | 8012542007555 |
| Catalog Description: | Summer/winter electronic thermostat, relay output, 1 NO contact 8A (AC1)/2A (AC15) - Power supply 230V~ 50/60Hz |
| Long Description: | Summer/winter electronic thermostat, relay output, 1 NO contact 8A (AC1)/2A (AC15) - Power supply 230V~ 50/60Hz |
| |
| Product Name: | Summer/winter electronic thermostat, relay output, 1 NO contact 8A (AC1)/2A (AC15) - Power supply 230V~ 50/60Hz |
| Rated Current (In): | 8 A |
| Power Consumption (@P | |
| cons | 0.5 W |
| Number of Main Contacts NO: | 1 |
| Number of Outputs: | Heater 0 |
| Cooler 0 | |
| Control Characteristic: | PID |
| Operating Mode: | Button |
| Connection Type: | Two Wired |
| Mounting Type: | Flush mounted (plaster) |
| Sensor Type: | Resistance sensor |
| Surface Finishing: | Basic |
| Material: | Plastic |
| Illumination: | Non-illuminated |
| Thermal Feedback: | Series |
| RAL Number: | RAL 9003 - Signal White |
| Color: | Clear white |
| |
| Degree of Protection: | IP30 |
| Temperature Class Default: | II |
| |
| Width in Number of Modular Spacings: | 2 |
| Product Net Width: | 55 mm |
| Product Net Height: | 60 mm |
| Product Net Depth / Length: | 50 mm |
| Product Net Weight: | 0.007 kg |
| |
| Package Level 1 Units: | box 1 piece |
| Package Level 1 Width: | 50 mm |
| Package Level 1 Height: | 60 mm |
| Package Level 1 Depth / Length: | 0.055 m |
| Package Level 1 Gross Weight: | 0.068 kg |
| Package Level 1 EAN: | 8012542007555 |
| Package Level 2 Units: | 6 piece |
| Package Level 2 Width: | 0.105 m |
| Package Level 2 Height: | 0.07 m |
| Package Level 2 Depth / Length: | 0.17 m |
| Package Level 2 Gross Weight: | 0.474 kg |
| Package Level 2 EAN: | 8012542007562 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85365080 |
| Country of Origin: | Italy (IT) |
| Selling Unit of Measure: | piece |
| |
| Declaration of Conformity - CE: | No declaration needed |
| Instructions and Manuals: | 2CSU600002D0901 |
| Popular Downloads | |
| Data Sheet, Technical Information: | 2CSU600002D0901 |
| Instructions and Manuals: | 2CSU600002D0901 |
| |
| ETIM 6: | EC000194 - Room temperature controller |
| ETIM 7: | EC010927 - Room thermostat |
| ETIM 8: | EC010927 - Room thermostat |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Consumer |
| CN8: | 8536500080 |
