BCM/S8.0.2.1 BAC Module, 8 Digital Outputs, 230 V, 0.3 A
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | BCM/S8.0.2.1 |
| Product ID: | 2CDG120066R0011 |
| EAN: | 4016779064446 |
| Catalog Description: | BCM/S8.0.2.1 BAC Module, 8 Digital Outputs, 230 V, 0.3 A |
| Long Description: | Extension module for the BAC/S Building Automation Controller KNX with 8 digital outputs. The digital triac outputs switch a maximum of 0.3 A at 120/240 V AC. Connection of the cables via pluggable spring terminals. |
| |
| Product Name: | Heating, Ventilation and Air Conditioning |
| Auxiliary Voltage AC/DC: | 24 V DC |
| Maximum Switching Current: | 0.3 mA |
| Number of Outputs: | 8 |
| Number of Digital Inputs: | 0 |
| Compatible Bus Systems: | Other |
| Mounting Type: | DIN-Rail |
| Surface Mounted | |
| Manual Operation: | No |
| Color: | Grey |
| Number of Batteries: | 0 |
| |
| Degree of Protection: | IP20 |
| RoHS Status: | No declaration needed |
| |
| Product Net Width: | 34 mm |
| Product Net Height: | 135 mm |
| Product Net Depth / Length: | 74 mm |
| Product Net Weight: | 0.18 kg |
| |
| Package Level 1 Units: | box 1 piece |
| Package Level 1 Width: | 150 mm |
| Package Level 1 Height: | 80 mm |
| Package Level 1 Depth / Length: | 50 mm |
| Package Level 1 Gross Weight: | 0.22 kg |
| Package Level 1 EAN: | 4016779064446 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85371091 |
| E-Number (Finland): | 2814622 |
| E-Number (Sweden): | 1739820 |
| Country of Origin: | China (CN) |
| Selling Unit of Measure: | piece |
| |
| Declaration of Conformity - CE: | 9AKK107046A7505 |
| Instructions and Manuals: | 9AKK107046A7505 |
| RoHS Information: | No declaration needed |
| Popular Downloads | |
| Data Sheet, Technical Information: | 9AKK107046A7505 |
| Instructions and Manuals: | 9AKK107046A7505 |
| |
| ETIM 6: | EC001419 - PLC digital I/O-module |
| ETIM 7: | EC001419 - PLC digital I/O-module |
| ETIM 8: | EC001419 - PLC digital I/O-module |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Consumer |
| CN8: | 8537 10 91 |
| eClass: | V11.0 : 27242204 |
| Object Classification Code: | A |
