BCM/S2.6.0.1 BAC Module with Temperature Sensor, 2 Analogue Inputs
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | BCM/S2.6.0.1 |
| Product ID: | 2CDG120068R0011 |
| EAN: | 4016779064460 |
| Catalog Description: | BCM/S2.6.0.1 BAC Module with Temperature Sensor, 2 Analogue Inputs |
| Long Description: | Extension module for the BAC/S Building Automation Controller KNX with 2 analog inputs for temperature sensors. Temperature sensors of type Pt100, Pt1000, Ni100, Ni1000 and 150 Ohm, 300 Ohm are supported. Connection of the cables via pluggable spring terminals. |
| |
| Product Name: | Heating, Ventilation and Air Conditioning |
| Auxiliary Voltage AC/DC: | 24 V DC |
| Power Loss: | 1.1 W |
| Number of Outputs: | 0 |
| Number of Digital Inputs: | 0 |
| Compatible Bus Systems: | Other |
| Mounting Type: | DIN-Rail |
| Surface Mounted | |
| Manual Operation: | No |
| Color: | Grey |
| Number of Batteries: | 0 |
| |
| Degree of Protection: | IP20 |
| RoHS Status: | No declaration needed |
| |
| Product Net Width: | 34 mm |
| Product Net Height: | 135 mm |
| Product Net Depth / Length: | 74 mm |
| Product Net Weight: | 0.19 kg |
| |
| Package Level 1 Units: | box 1 piece |
| Package Level 1 Width: | 175 mm |
| Package Level 1 Height: | 95 mm |
| Package Level 1 Depth / Length: | 65 mm |
| Package Level 1 Gross Weight: | 0.23 kg |
| Package Level 1 EAN: | 4016779064460 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85371091 |
| E-Number (Finland): | 2814624 |
| E-Number (Sweden): | 1739822 |
| E-Number (Switzerland): | 405630015 |
| Country of Origin: | China (CN) |
| Selling Unit of Measure: | piece |
| |
| Declaration of Conformity - CE: | 9AKK107046A7503 |
| Instructions and Manuals: | 9AKK107046A7503 |
| RoHS Information: | No declaration needed |
| Popular Downloads | |
| Data Sheet, Technical Information: | 9AKK107046A7503 |
| Instructions and Manuals: | 9AKK107046A7503 |
| |
| ETIM 6: | EC001420 - PLC analogue I/O-module |
| ETIM 7: | EC001420 - PLC analogue I/O-module |
| ETIM 8: | EC001420 - PLC analogue I/O-module |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Consumer |
| CN8: | 8537 10 91 |
| eClass: | V11.0 : 27242201 |
| Object Classification Code: | A |
