General Information | |
| Extended Product Type: | MACN202AR |
| Product ID: | 1SAL103558R9906 |
| EAN: | 4013614550270 |
| Catalog Description: | MACN202AR Auxiliary Contact Block |
| Long Description: | MACN202AR Auxiliary Contact 2NC ring tongue terminal, front mounted EN 50012 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85365080 |
| Popular Downloads | |
| Instructions and Manuals: | 2CDC102075M9901 |
| |
| Product Net Width: | 45 mm |
| Product Net Height: | 27 mm |
| Product Net Depth / Length: | 35 mm |
| Product Net Weight: | 0.03 kg |
| |
| Rated Operational Voltage: | Auxiliary Circuit 690 V AC |
| Auxiliary Circuit 440 V DC | |
| Rated Frequency (f): | Auxiliary Circuit 50 Hz |
| Auxiliary Circuit 60 Hz | |
| Auxiliary Circuit DC | |
| Rated Impulse Withstand Voltage (Uimp): | Auxiliary Circuit 6 kV |
| Rated Insulation Voltage (Ui): | 750 V |
| Degree of Protection: | IP20 |
| Connecting Capacity Auxiliary Circuit: | Flexible 1/2x 0.75 ... 2.5 mm² |
| Rigid 1/2x 0.75 ... 2.5 mm² | |
| Tightening Torque: | Auxiliary Circuit 0.8 N·m |
| Wire Stripping Length: | Auxiliary Circuit 9 mm |
| Recommended Screw Driver: | Auxiliary Circuit Pozidriv 2 |
| Standards: | IEC/EN 60947-1 |
| IEC/EN 60947-5-1 | |
| UL 60947-1 | |
| UL 60947-5-1 | |
| Number of Auxiliary Contacts NO: | 0 |
| Number of Auxiliary Contacts NC: | 2 |
| Number of Main Contacts NC: | 0 |
| Number of Main Contacts NO: | 0 |
| Conventional Free-air Thermal Current (Ith): | Auxiliary Circuit 10 A |
| Product Name: | Auxiliary Contact Block |
| Suitable For: | MC1 |
| MC2 equipped with Ring Tongue terminals | |
| Suitable for Product Class: | Mini Contactors |
| Technical UL/CSA | |
| Maximum Operating Voltage UL/CSA: | Auxiliary Circuit 600 V AC/DC |
| Connecting Capacity Auxiliary Circuit UL/CSA: | Stranded 18-12 AWG |
| Tightening Torque UL/CSA: | Auxiliary Circuit 7 in·lb |
| Contact Rating UL/CSA: | A600 |
| Q600 | |
| |
| Ambient Air Temperature: | Operation -40 ... +55 °C |
| Storage -55 ... +80 °C | |
| Maximum Operating Altitude Permissible: | 3000 m |
| RoHS Status: | Following EU Directive 2011/65/EU |
| |
| CB Certificate: | 1SAA971003-2001 |
| CQC Certificate: | CQC2019010304193152 |
| cULus Certificate: | cUL_E48139 |
| Declaration of Conformity - CCC: | 2020980304001603 |
| Declaration of Conformity - CE: | 1SAD938503-0305 |
| Declaration of Conformity - UKCA: | 1SAD938500-1305 |
| Instructions and Manuals: | 2CDC102075M9901 |
| RINA Certificate: | 1SAA971000-0801 |
| RoHS Information: | 1SAD938503-0305 |
| |
| Package Level 1 Width: | 100 mm |
| Package Level 1 Depth / Length: | 30 mm |
| Package Level 1 Height: | 100 mm |
| Package Level 1 Gross Weight: | 0.035 kg |
| Package Level 1 EAN: | 4013614550270 |
| Package Level 1 Units: | bag 1 piece |
| Package Level 2 Width: | 100 mm |
| Package Level 2 Depth / Length: | 150 mm |
| Package Level 2 Height: | 105 mm |
| Package Level 2 Gross Weight: | 0.35 kg |
| Package Level 2 EAN: | 4013614550768 |
| Package Level 2 Units: | box 10 piece |
| |
| Object Classification Code: | K |
| ETIM 5: | EC000041 - Auxiliary contact block |
| ETIM 6: | EC000041 - Auxiliary contact block |
| ETIM 7: | EC000041 - Auxiliary contact block |
| eClass: | V11.0 : 27371302 |
| UNSPSC: | 39121522 |
| E-Number (Finland): | 3709644 |
