General Information | |
| Global Commercial Alias: | EP33C02 |
| Extended Product Type: | EP33C02 |
| Product ID: | 2CDB101301R0024 |
| EAN: | 5413656709169 |
| Catalog Description: | EP33C02 Miniature Circuit Breaker |
| Long Description: | MCB EP30 3kA 3P C 2A |
| |
| Standards: | IEC/EN 60898-1 |
| IEC/EN 60947-2 | |
| Product Name: | Miniature Circuit Breaker |
| Tripping Characteristic: | C |
| Rated Operational Voltage: | 400 V AC |
| Rated Insulation Voltage (Ui): | acc. to IEC/EN 60664-1 440 V |
| Rated Impulse Withstand Voltage (Uimp): | 6 kV |
| Input Voltage Type: | AC |
| Rated Current (In): | 2 A |
| Rated Short-Circuit Capacity (Icn): | (400 V AC) 3 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu): | (230 V AC) 5 kA |
| Rated Conditional Short-Circuit Current (Inc): | (400 V) 5 kA |
| Rated Frequency (f): | 50 / 60 Hz |
| Energy Limiting Class: | 3 |
| Number of Poles: | 3 |
| Number of Protected Poles: | 3 |
| Overvoltage Category: | III |
| Accessories Available: | Yes |
| Number of Batteries: | 0 |
| Connecting Capacity: | Flexible 0.75 ... 25 mm² |
| Rigid 1 ... 35 mm² | |
| |
| Ambient Air Temperature: | Operation -20 ... +55 °C |
| Degree of Protection: | IP20 |
| Pollution Degree: | 2 |
| RoHS Status: | Following EU Directive 2011/65/EU |
| |
| Width in Number of Modular Spacings: | 3 |
| Product Net Width: | 0.054 m |
| Product Net Height: | 0.086 m |
| Product Net Depth / Length: | 0.076 m |
| Product Net Weight: | 0.36 kg |
| Built-In Depth (t2): | 70 mm |
| |
| Package Level 1 Units: | pack 1 piece |
| Package Level 1 Width: | 0.055 m |
| Package Level 1 Height: | 0.078 m |
| Package Level 1 Depth / Length: | 0.094 m |
| Package Level 1 Gross Weight: | 0.379 kg |
| Package Level 1 EAN: | 5413656709169 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85362010 |
| Country of Origin: | Poland (PL) |
| Selling Unit of Measure: | piece |
| |
| Certification Agency: | EN |
| IEC | |
| Declaration of Conformity - CE: | 9AKK107991A0939 |
| Instructions and Manuals: | No document needed |
| Popular Downloads | |
| Data Sheet, Technical Information: | No document needed |
| Instructions and Manuals: | No document needed |
| |
| ETIM 6: | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 7: | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 8: | EC000042 - Miniature circuit breaker (MCB) |
| EPLAN Catalog Tree: | Electrical engineering / Protection devices / General |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Consumer |
| CN8: | 8536 20 10 |
| UNSPSC: | 39121614 |
| eClass: | V11.0 : 27141901 |
| Object Classification Code: | Q |
