Article: 316Schuko
Article: 316Schuko
Adapter 3P+E 16A IEC to 2 pole 10/16A Schuko outlet
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | 316Schuko |
| Product ID: | 2CMA170256R1000 |
| EAN: | 7392696702638 |
| Catalog Description: | Adapter 3P+E 16A IEC to 2 pole 10/16A Schuko outlet |
| Long Description: | Adapter 3P+E 16A IEC to 2 pole 10/16A Schuko outlet |
| |
| E-Number (Sweden): | 91565591 |
| EAN: | 7392696702638 |
| Country of Origin: | Czech Republic (CZ) |
| Minimum Order Quantity: | 10 piece |
| |
| Product Net Width: | 66 mm |
| Product Net Height: | 71.9 mm |
| Product Net Weight: | 0.250 kg |
| |
| Package Level 1 Width: | 138 mm |
| Package Level 1 Depth / Length: | 158 mm |
| Package Level 1 Height: | 345 mm |
| Package Level 1 Gross Weight: | 0.25 kg |
| Package Level 1 EAN: | 7392696702638 |
| Package Level 1 Units: | box 10 piece |
| |
| RoHS Status: | Following EU Directive 2011/65/EU |
| |
| Declaration of Conformity - CE: | 2CMC700005D0001 |
| Environmental Information: | 2CMC000056M0000 |
| RoHS Information: | 2CMC700005D0001 |
| REACH Declaration: | 2CMC700005D0001 |
| |
| Additional Information: | 3P+E |
| Ambient Temperature: | -25 ... 40 °C |
| Cable Length: | 0 m |
| Color: | Blue |
| Degree of Protection: | IP44 |
| Frequency (f): | 50 Hz |
| 60 Hz | |
| Function: | Adaptor |
| Housing Material: | Plastic |
| Invoice Description: | Ind. P&S#316Schuko |
| Mounting Type: | Portable |
| Number of Poles: | 4 |
| Object Classification Code: | 2CMT005069 |
| Order Multiple: | 10 piece |
| Product Main Type: | Schuko |
| Product Name: | Industrial Plugs and Sockets Accessorie |
| Protection Type: | None |
| Rated Current (In): | 16 A |
| Rated Voltage (Ur): | 200 ... 250 V |
| Standards: | IEC 60309-1, -2 |
| Suitable for Product Class: | IEC Industrial Plugs and Sockets |
| Instructions and Manuals: | 2CMC700014C0016 |
| RAL Number: | RAL 7001 - Silver Grey |
| |
| UNSPSC: | 39120000 |
