CL-LER.18DC2 Expansion for logic relays 24VDC, 12I/6O, relay
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | CL-LER.18DC2 |
| Product ID: | 1SVR440721R0000 |
| EAN: | 4013614389641 |
| Catalog Description: | CL-LER.18DC2 Expansion for logic relays 24VDC, 12I/6O, relay |
| Long Description: | The CL-LER.18DC2 is an expansion from the CL range. It has 12 digital inputs and 6 relay outputs. The expansion operates with an input voltage of 24 V DC and can be connected to a logic relay or display base module via CL-LINK. The package contains a connecting plug (CL-LINK). |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85364900 |
| Popular Downloads | |
| Data Sheet, Technical Information: | 2CDC110004C0210_05 |
| Instructions and Manuals: | 1SVC440796M3000 |
| |
| Product Net Width: | 107.5 mm |
| Product Net Depth / Length: | 58 mm |
| Product Net Height: | 90 mm |
| Product Net Weight: | 0.22 kg |
| |
| Function: | Expansions |
| Sub-Function: | Input / Output expansion |
| Number of Digital In/Outputs: | 12 Digital Inputs / 6 Relay Outputs |
| Rated Operational Voltage: | 24 V DC |
| |
| RoHS Status: | Following EU Directive 2011/65/EU |
| |
| CSA Certificate: | CSA_1875990 |
| Declaration of Conformity - CE: | 1SVD982003-0001 |
| EAC Certificate: | EAC_RU_C-DE.AB72.B.01802 |
| Environmental Information: | 1SAA981012-2401 |
| Instructions and Manuals: | 1SVC440796M3000 |
| RoHS Information: | 1SVD982003-0001 |
| UL Certificate: | UL_E179811 |
| |
| Package Level 1 Units: | 1 piece |
| Package Level 1 Width: | 94 mm |
| Package Level 1 Height: | 70 mm |
| Package Level 1 Depth / Length: | 112 mm |
| Package Level 1 Gross Weight: | 0.266 kg |
| Package Level 1 EAN: | 4013614389641 |
| |
| Object Classification Code: | K |
| ETIM 4: | EC001417 - Logic module |
| ETIM 5: | EC001417 - Logic module |
| ETIM 6: | EC001417 - Logic module |
| ETIM 7: | EC001417 - Logic module |
| eClass: | V11.0 : 27242216 |
