Article: AF145
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | AF145 |
| Product ID: | 1SFN164703R9100 |
| EAN: | 7320500252628 |
| Catalog Description: | AF145 48-130V 50/60Hz / DC Replacement Kit |
| Long Description: | AF145 48-130V 50/60Hz / DC Replacement Kit |
| |
| Product Name: | Replacement Kit |
| Suitable For: | AF145 |
| Power Loss: | at Rated Operating Conditions per Pole 5 W |
| Coil Consumption: | Holding at Max. Rated Control Circuit Voltage 50 Hz 12 V·A |
| Holding at Max. Rated Control Circuit Voltage 60 Hz 12 V·A | |
| Holding at Max. Rated Control Circuit Voltage DC 2 W | |
| Pull-in at Max. Rated Control Circuit Voltage 50 Hz 430 V·A | |
| Pull-in at Max. Rated Control Circuit Voltage 60 Hz 430 V·A | |
| Pull-in at Max. Rated Control Circuit Voltage DC 500 W | |
| |
| RoHS Status: | Following EU Directive 2011/65/EU |
| |
| Product Net Width: | 105 mm |
| Product Net Height: | 98 mm |
| Product Net Depth / Length: | 160 mm |
| Product Net Weight: | 0.24 kg |
| |
| Package Level 1 Units: | box 1 piece |
| Package Level 1 Width: | 170 mm |
| Package Level 1 Height: | 170 mm |
| Package Level 1 Depth / Length: | 140 mm |
| Package Level 1 Gross Weight: | 0.24 kg |
| Package Level 1 EAN: | 7320500252628 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85389099 |
| Country of Origin: | Sweden (SE) |
| Selling Unit of Measure: | piece |
| |
| CQC Certificate: | CQC2007010304256685 |
| CQC2009010304353527 | |
| Declaration of Conformity - CCC: | 2020980304001634 |
| 2020980304001069 | |
| Declaration of Conformity - CE: | 2CMT2015-005436 |
| Instructions and Manuals: | N/A |
| RoHS Information: | 2CMT2015-005436 |
| Popular Downloads | |
| Instructions and Manuals: | N/A |
| |
| ETIM 6: | EC002498 - Accessories for low-voltage switch technology |
| ETIM 7: | EC002498 - Accessories for low-voltage switch technology |
| ETIM 8: | EC002498 - Accessories/spare parts for low-voltage switch technology |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Business |
| CN8: | 8538 90 99 |
| Object Classification Code: | Q |
