General Information
Global Commercial Alias:	EM4400T-G
Product ID:	7BEM4400T-G
ABB Type Designation:	100HP,1785RPM,3PH,60HZ,405T,A40064M
Catalog Description:	100HP,1785RPM,3PH,60HZ,405T,A40064M,TEFC
Additional Information
ABB Type Designation:	100HP,1785RPM,3PH,60HZ,405T,A40064M
Ambient Temperature:	40 °C
Brake Present:	No
Brand / Label:	Baldor-Reliance
Catalog Number:	EM4400T-G
Certification Agency:	CCSA US
CSA EEV
Country of Origin:	United States (US)
Customs Tariff Number:	85015230
Design:	B
Dimension Diagram:	617429-001
Drive End Flange Type:	Standard
Duty Time:	60 Min
ETIM 7:	EC001851 - Electric motor
Efficiency Level:	Premium Efficiency (NEMA 12-12)

Electrical Data:

Current	Freq	Power	Speed	Voltage
224 A	60 Hz	100 Hp	1785 r/min	230 V
112 A	60 Hz	100 Hp	1785 r/min	460 V
206 A	50 Hz	75 Hp	1485 r/min	190 V
103 A	50 Hz	75 Hp	1485 r/min	380 V

Enclosure Type: TEFC
Frame Material: Iron
Frequency (f): 50.00 Hz

60.00 Hz
Global Commercial Alias: EM4400T-G
Gross Weight: 551.156 kg
Horsepower Rating UL/CSA: 100.000 Hp
IDEA Granular Category Code (IGCC): 1318 >> Heating and cooling system motor AC
Insulation Class: H
Invoice Description: 100HP,1785RPM,3PH,60HZ,405T,A40064M,TEFC
Made To Order: No
Minimum Order Quantity: 1 piece
Motor Base Type: Rigid
Motor Frame Size: 405T
Mounting Position: F1
NEMA Design Code: B
Number of Phases: 3
Number of Poles: 4
Number of Speeds: Single Speed
Order Multiple: 1 piece
Output Power: 100.000 Hp

75.000 Hp
Power Factor: 87 %
Product Name: HVAC Motors
Product Net Height: 0 cm
Product Net Length: 0 cm
Product Net Weight: 551.156 kg
Product Net Width: 0 cm
Product Type: Undefined
Quote Only: No
Rated Current (I_n): 224 A

112 A
Rated Efficiency: 95.4 %
Rated Speed: 1,785 r/min
Selling Unit of Measure: piece
Service Factor: 1.15
Service Factor Percentage: 1.15 %
Shaft Diameter: 2.875 in
Standards: NEMA
Starting of Motor: Direct On Line
Stocked At (Warehouses): China

Alabama, United States

Alaska, United States
Type of Duty: Continuous
UNSPSC: 26101105
Voltage Rating: 190 V

230 V
