General Information | |
| Extended Product Type: | VH 300 |
| Product ID: | SK829071-B |
| EAN: | 7320500052693 |
| Catalog Description: | VH 300 Mechanical Interlock Unit |
| Long Description: | Mechanical interlock for two horizontally mounted contactors designed to prevent one of the contactors from closing while the other contactor is closed |
| |
| Product Name: | Mechanical Interlock Unit |
| Suitable For: | EK175/EK210 |
| Rated Insulation Voltage (Ui): | acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 690 V |
| Rated Operational Current AC-15 (Ie): | (500 V) 1 A |
| (690 V) 1 A | |
| (24 / 127 V) 6 A | |
| (220 / 240 V) 6 A | |
| (380 / 400 V) 4 A | |
| Rated Short-time Withstand Current (Icw): | for 0.1 s 140 A |
| for 1 s 100 A | |
| Rated Frequency (f): | Supply Circuit 50 / 60 Hz |
| Power Loss: | at Rated Operating Conditions per Pole 0.1 W |
| Short-Circuit Protective Devices: | Auxiliary Circuit - gG Type Fuses 10 A |
| |
| RoHS Status: | Following EU Directive 2011/65/EU |
| |
| Product Net Width: | 445 mm |
| Product Net Height: | 230 mm |
| Product Net Depth / Length: | 30 mm |
| Product Net Weight: | 0.13 kg |
| |
| Package Level 1 Units: | bag 1 piece |
| Package Level 1 Width: | 586 mm |
| Package Level 1 Height: | 295 mm |
| Package Level 1 Depth / Length: | 62 mm |
| Package Level 1 Gross Weight: | 0.28 kg |
| Package Level 1 EAN: | 7320500052693 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85369001 |
| E-Number (Norway): | 3214363 |
| E-Number (Sweden): | 3214363 |
| Country of Origin: | India (IN) |
| Selling Unit of Measure: | piece |
| |
| Declaration of Conformity - CE: | N/A |
| Instructions and Manuals: | N/A |
| RoHS Information: | 2CMT2016-006087 |
| Popular Downloads | |
| Instructions and Manuals: | N/A |
| |
| ETIM 6: | EC002498 - Accessories for low-voltage switch technology |
| ETIM 7: | EC002498 - Accessories for low-voltage switch technology |
| ETIM 8: | EC002498 - Accessories/spare parts for low-voltage switch technology |
| WEEE Category: | Product Not in WEEE Scope |
| WEEE B2C / B2B: | Business To Business |
| CN8: | 8536 90 01 |
| Object Classification Code: | R |
