General Information | |
| Global Commercial Alias: | VM8537 |
| Product ID: | 7BVM8537 |
| ABB Type Designation: | .5HP,3450RPM,3PH,60HZ,56C,3410M,TEF |
| Catalog Description: | .5HP,3450RPM,3PH,60HZ,56C,3410M,TEFC,F1 |
| |
| ABB Type Designation: | .5HP,3450RPM,3PH,60HZ,56C,3410M,TEF |
| Country of Origin: | United States (US) |
| Customs Tariff Number: | 85015100 |
| Design: | B |
| Enclosure Type: | TEFC |
| Frame Material: | Steel |
| Frequency (f): | 60 Hz |
| Global Commercial Alias: | VM8537 |
| Gross Volume: | 1557.5 in³ |
| Gross Weight: | 11.35 kg |
| Horsepower Rating UL/CSA: | 0.500 Hp |
| Invoice Description: | .5HP,3450RPM,3PH,60HZ,56C,3410M,TEFC,F1 |
| Made To Order: | No |
| Minimum Order Quantity: | 1 piece |
| Motor Base Type: | No Mounting |
| Motor Frame Size: | 56C |
| Number of Phases: | 3 |
| Number of Poles: | 2 |
| Number of Speeds: | Single Speed |
| Order Multiple: | 1 piece |
| Power Factor: | 63 % |
| Product Name: | LV Severe Duty Motors |
| Product Net Height: | 25.4 cm |
| Product Net Length: | 35.56 cm |
| Product Net Weight: | 11.35 kg |
| Product Net Width: | 28.258 cm |
| Product Type: | Undefined |
| Quote Only: | No |
| Rated Current (In): | 2 A |
| 1 A | |
| Rated Efficiency: | 68.0 % |
| Rated Speed: | 3,450 r/min |
| RoHS Information: | RoHS Compliant |
| Selling Unit of Measure: | piece |
| Service Factor Percentage: | 1.25 % |
| Stocked At (Warehouses): | China |
| Alaska, United States | |
| UNSPSC: | 26101112 |
| Voltage Rating: | 460 V |
| 230 V |
