Article: CM-IWN-AC
Article: CM-IWN-AC
CM-IWN-AC Insulation monitor 1c/o, 1-110kOhm, A1-A2=24-240VAC/DC
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | CM-IWN-AC |
| Product ID: | 1SVR450075R0000 |
| EAN: | 4013614347269 |
| Catalog Description: | CM-IWN-AC Insulation monitor 1c/o, 1-110kOhm, A1-A2=24-240VAC/DC |
| Long Description: | CM-IWN-AC Insulation monitor 1c/o, 1-110kOhm, A1-A2=24-240VAC/DC |
| |
| EAN: | 4013614347269 |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85364900 |
| |
| Package Level 1 Units: | 1 piece |
| Package Level 1 Width: | 81 mm |
| Package Level 1 Height: | 106 mm |
| Package Level 1 Depth / Length: | 46 mm |
| Package Level 1 Gross Weight: | 0.233 kg |
| Package Level 1 EAN: | 4013614347269 |
| |
| Product Net Width: | 45 mm |
| Product Net Depth / Length: | 100 mm |
| Product Net Height: | 78 mm |
| Product Net Weight: | 0.207 kg |
| |
| Function: | Unearthed AC systems |
| Up to 400 V AC | |
| Measuring Range: | 1 ... 11 kΩ |
| Rated Control Supply Voltage (Us): | 24 ... 240 V AC/DC |
| Output: | 1 c/o (SPDT) contact |
| |
| RoHS Status: | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
| |
| CB Certificate: | CB_DK-8882 |
| CCC Certificate: | CCC_2005010303165477 |
| cUL Certificate: | cUL508_E140448 |
| Data Sheet, Technical Information: | 2CDC110004C0207_02 |
| Declaration of Conformity - CE: | 1SAD938501-0136 |
| Environmental Information: | 1SAA981003-2403 |
| GL Certificate: | GL_96663-95HH |
| GOST Certificate: | GOST_POCC_DE.ME77.B07067 |
| Instructions and Manuals: | 1SVC457062M1000 |
| RMRS Certificate: | RMRS_05.04072.011 |
| RoHS Information: | 1SAA981031-4401 |
| UL Certificate: | UL508_E140448 |
| |
| Object Classification Code: | B |
| ETIM 4: | EC001444 - Insulation and earth fault monitoring relay |
| ETIM 5: | EC001444 - Insulation and earth fault monitoring relay |
| ETIM 6: | EC001444 - Insulation and earth fault monitoring relay |
| ETIM 7: | EC001444 - Insulation and earth fault monitoring relay |
| eClass: | V11.0 : 27371807 |
