Article: DS2C-CM
We find the right product
for you
Official reseller
Expert engineering support
Configuration
General Information | |
| Extended Product Type: | DS2C-CM |
| Product ID: | 2CSR201997R0013 |
| EAN: | 8012542135951 |
| Catalog Description: | DS2C-CM Motor operating device |
| Long Description: | The DS2C-CM motor operating device has the function to allow the remote control (opening or closing) of the RCBO it is associated to. |
| |
| Product Name: | Motor operating device |
| Suitable For: | DS201 |
| DS202C | |
| Suitable for Product Class: | Residual Current Devices with Overcurrent Protection RCBOs |
| Rated Voltage (Ur): | 230 V |
| Power Loss: | 1.5 W |
| Number of Contacts CO: | 0 |
| Number of Contacts NC: | 0 |
| Number of Contacts NO: | 0 |
| |
| Product Net Width: | 0.055 m |
| Product Net Height: | 0.121 m |
| Product Net Depth / Length: | 0.085 m |
| Product Net Weight: | 0.163 kg |
| |
| Package Level 1 Units: | box 1 piece |
| Package Level 1 Width: | 0.091 m |
| Package Level 1 Height: | 0.09 m |
| Package Level 1 Depth / Length: | 0.092 m |
| Package Level 1 Gross Weight: | 0.360 kg |
| Package Level 1 EAN: | 8012542135951 |
| |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85389099 |
| Country of Origin: | Italy (IT) |
| Selling Unit of Measure: | piece |
| |
| Declaration of Conformity - CE: | 9AKK106713A5575 |
| Instructions and Manuals: | 9AKK107680A3324 |
| Popular Downloads | |
| Data Sheet, Technical Information: | 2CSC422004B0203 |
| Instructions and Manuals: | 9AKK107680A3324 |
| |
| ETIM 6: | EC001286 - Auxiliary contact unit for distribution board |
| ETIM 7: | EC001286 - Auxiliary device for distribution board devices |
| ETIM 8: | EC001286 - Auxiliary device for distribution board devices |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Consumer |
| CN8: | 85389099 |
| Object Classification Code: | Q |
